Specification:

MMGX-10

Power, V:

380VAC

Installed Power, kw:

2.2

ChainSpeed, mm/min:

700

Work Area Size (L* W* H ), mm:

1700x400x550

Contour Size (L* W *H ), mm:

10000x2000x3000

Weight, kg:

4500

PATENT NO. :

200720158455.1

Description: Shell making and drying line of delivering with cross bars lifted by multi-chains is mainly applied in shell hanging, drying and transportation in investment casting industry. It dries shell more evenly than ordinary shell stand. The main body if the drying line is welded with 14# channel steel, with simple structure and liable strenth, convinient for maintenance. The chain size conforms to national standard. It is designed by considering the application and maintenance process adequately, so all the chains is exposed to view for easy check and repair. Catenary chain shell drying line has been the essential eqipment in investment casting industry. We also design and manufecture shell making and drying line of different production length and hanging room according to customers requirements. Frequency variable and energy saving devices for drying line is also available.
